一、Features

1. Sweden PROFLUTE silicon gel wheel

2. Equipped with easy to uninstall and easily washed plate type pre-filter and bag type filter

3. High strength aluminium alloy frame, anti-cold bridge

4. Machine body adopts international fashionable modularization design, foam injected double wall casing, excellent heat and humidity isolation, no dew forming.

5．PLC automatic control system, human-machine interface

6. Electric or steam heating or convert type can be available

7. Modularization designed, can be stand-alone or combined with air-conditioning unit

8. The process airflow can be set from 100m³/h to 50000 m³/h according to customer’s requirement.

二、Details

The rotary wheel is divided into 3/4 adsorption area and 1/4 regeneration area. When the process air goes through the adsorption area of the wheel, the moisture is adsorbed by adsorbent, after that the dried air is discharged to certain room by fan motor. At the same time, counterflow regeneration air(electric or steam heated) goes to regenerate the wheel in regeneration area, collecting the moisture wheel adsorbed and leaving as wet steam. The wheel is rotated at the speed of 8 to 12 cycles per hour by the drive motor, making the dehumidifying and regeneration continuous.

三、The main parameters
