Reference standard: GB/T 11158-2008 Technical Conditions for High Temperature Test Chambers;

?

Air-way system: a new air-way system design, three sides of the air, good temperature uniformity in different locations within the?chamber;

?

Control system: three-level permission programmable color touch screen controller;

?

Chamber Materials：The exterior is coated with high quality steel plate,The liner is made of mirror stainless steel;

?

Data management: Configure electronic data storage function, which can export data through a USB flash drive;

?

Safety device: Equipped with an independent overtemperature protection system to protect the safety of samples and equipment;

?

Temperature control accuracy: Temperature fluctuation ≤ ± 0.5 ℃ , temperature deviation ≤ ± 2.0 ℃ (below 150℃)Temperature deviation ≤ ± 3.0 ℃ (below 300 ℃ ).

?

Name

Model

Temperature Range

( ℃ )

Capacity

(L)

Interior Dimensions(mm)

W×D×H

External Dimensions(mm)

W×D×H

Power

( kW )

Shelf?

(Standard)

Remarks

?

High Temperature Chamber

(300℃ )

Labonce-100GWH

RT+10 ~ 300

100

450×450×450

1100×700×800

2.5

2

Temperature

deviation (℃):

± 3.0

Labonce-250GWH

RT+10 ~ 300

250

600×600×700

1250×850×1000

3.0

2

Labonce-500GWH

RT+10 ~ 300

500

800×700×900

1450×1200×1200

4.0

2

Labonce-1000GWH

RT+10 ~ 300

1000

1000×1000×1000

1650×1650×1300

4.5

4
