Technical Parameters

Specifications

NJP-5500C

Maximum yield

330000 Capsules/hour

machine weight

3200 kg

Machine volume

1548×1313×2305mm (height with automatic powder feeder: 2900mm)

power supply

Three-phase five-wire AC 380/220V 50Hz

total power

12kw

Number of holes

40 holes

Vacuum

-0.02～-0.06MPa

vacuuming

24.5Kpa 210m3/h

compressed air

Air consumption 12m3/h Pressure 0.3～0.4MPa

working noise

≤78dBA

Working temperature

21°C±3°C

working relative humidity

40-55%

Capsule on chance

Empty capsule ≥ 99.9% Full capsule ≥ 99.8%

Adapt Capsules

00#-5# capsule/safety capsule AE

Loading accuracy

Western medicine ±3% Traditional Chinese medicine ±4%

Adapt to the filling range

Powder, Granule, Pellet, Tablet

special function

Powder collector function

Material

316 stainless steel is used for parts in direct contact with medicines

specification

Fully sign cGMP requirements
