Technical parameter
     Precision: ≤5‰
     Stroke length: 6000 steps (60mm)
     Control precision: 1 step (0.01mm)
     Speed: 0.05-50mm/s
     single stroke operating time:1.2--1200s
     Compatible Syringe: 50ul,100ul,250ul,500ul,1ml,2.5ml,5ml,10ml,25ml
     Valve type: two position three way electromagnetic valve
     Turn time: ≤100ms
     Max pressure: 0.1MPa
     Fluid Path: borosilicate glass, PTEF, PEEK
     Valve fitting: 1/4″-28UNF inner thread interface
     Output signal: three OC gate
     Communication interface: RS232/485 options
     The rate of communication: 9600/38400bps options
     Set up pump address: through 16 digit dial switch
     Dimensions : 114mm×45mm×254mm
     Power: 24V DC/1.5A
     Operating condition: Temperature 15 to 40℃(the temperature effect syringe much)
     Relative humidity :80%
     Weight: 2KG

Optional accessories
Syringe
Tubing
Power adapter

Programmable Capabilities: Ramps, cutoff velocity, backlash compensation, syringe speeds, loops, terminate moves and delays, error detection, valve rotation selection, enhanced “h” factor capabilities including valve rotation CW and CCW.
