Material: Stainless Steel, or Ti
Heat Medium: Hot Water
Type of Heat Exchange: Tubular or Plate
Control System: Automatic, or Computer Control

Advantages:

1. All spliced angles inside the chamber are arc processed, and formed by compression molding. Arc angle R=30mm.
2. The door flange is plane processed. The mounting groove of the sealing strip is processed by numerical milling to guarantee the sealing effect of the door.
3. Door hinge is formed by stainless steel wire-electrode cutting, which can reduce pollution, increase strength and avoid the falling down of the door so that the door is easy to open.
4. Vacuum nozzle and nitrogen port are both designed with a filter, which can prevent airflow flowing backward and rushing at materials when the vacuum system fails.
5. Heat transfer from four sides of the shell. Uniform heating, small temp. difference, condensing avoided and drying efficiency improved.
6. Special external connection to avoid any internal leakage.
7. This product is in accordance with the requirements of GMP.
8. Our company can provide the relevant documents and service supports for GMP verification.
